| Place of Origin: | China |
|---|---|
| Brand Name: | CMT |
| Certification: | ISO |
| Model Number: | customization |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | standard export package |
| Delivery Time: | 120 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 sets/year |
| Constructional Speed: | 90m/Min | Line Center Height: | 1000mm |
|---|---|---|---|
| Installed Power: | 175kw | Turnkey Project: | Yes |
| Name: | Sheathing Line Production Line | Usage: | Galvanized Steel Wire Rope Sheating Machine |
| High Light: | cement bag making machine,cnc drilling machine |
||
Sheathing Line Production Line /Galvanized Steel Wire Rope Sheating Machine
We can design the production line according to your requirements. The following data is just for your refernence.
1. Application
The line is used to extrude sheathing for optical cable.
1.1 Produce inner sheathing on cable core
1.2 Produce outer sheathing in inner sheathed armored or non-metallic cable core.
1.3 Make sheathing on cable core with or without aluminum wrapped core.
1.4 The machine will be capable to produce Aerial access optical cable, ducted access optical cable, direct burried optical cable, ducted cable with moisture barrier.
1.5 The extruding materials: HDPE, LDPH will be used for inner and outer sheathing of optical cables.
2. Line Configurations
2.1 Suspended beam CSM payoff frame of 1800
2.2 Dual-reel tension dancer for cable core
2.3 Dual Pad Metal Tape Pay-off
2.4 On-line seam welding device for Steel(Aluminum) tape
2.5 Metal Tape (steel-aluminum ) accumulator
2.6 Metal Tape (Steel-Aluminum) corrugating device
2.7Jelly Filling Unit
2.8 waterproof yarns pay-off
2.9 Non-Driven device for rip cord pay-off
2.10 Metal Tape (Steel-Aluminum) longitudinal forming device
2.11 Adhesive-bonded fabric/non driven tape pay-off
2.12 SJ90×25 extruder and cross head
2.13 Vacuum application unit
2.14Loader and hopper compound dryer
2.15 Hot-water tank and 4m movable hot-water trough
2.16 24m stainless steel cooling-water trough
2.17 Blow dryer device
2.18 Diameter control device
2.19 Length number printer
2.20 AC spark tester device
2.21 Caterpillar 1250kg
2.22 Swaying beam type tension dancer for take-up
2.23 1800 take-up with traverse
2.24Electrical control system
3. Brief Description of Different Components of the Machine:
3.1 Suspended beam CSM payoff frame of 1800
Specifications
| Reel weight, max. | 5T |
| Reel diameter | 800-1800 mm |
| Speed degree | Two degree |
| Pay-off speed | ≤100m/min |
| Pay-off motor | 7.5kw AC motor |
| Driver | Danfoss |
| Traversing pitch | 5-35mm |
3.2 Dual-reel tension dancer for cable core
The machine is consisted of frame and two horizontal reels. The diameter of the two reels is 800mm. the one reel is the driving reel, another is the fixed reel. The tension is provided by pneumatic cylinder.
Specification
| Wheel diameter | 800 mm |
| Cable core diameter, max. | 50 mm |
| Tension range | 10-200N adjustable |
3.3 Dual Pad Metal Tape Pay-off
3.4 On-line seam welding device for Steel(Aluminum) tape
3.5 Metal Tape (steel-aluminum) accumulator
3.6 Metal Tape corrugating device
3.7Jelly Filling Unit
3.8 Waterproof yarns pay-off
3.9 Non-driven device for rip cord pay-off
3.10 Metal Tape longitudinal forming device
3.11Adhesive-bonded fabric/Non-driven tape pay-off
For the requirement of the much longer fibercable, the double reels have been designed. The bulge shafts have been designed for the tape reel installing conveniently. The magnetic brake controls the pay-off tension. The alarm device for the disconnecting of the tape has been designed.
For more information, please contact us at any time.
| Diameter of cable core | 3-30mm |
| Diameter of loose tube | 1.6-10.0 |
| Diameter of cable | 5-35mm |
| Line speed | 10--80m/min(cable dia:10mm) |
| constructional speed | 90m/min |
| Pay-off reel size | PN1000~PN1800 |
| Take-up reel size | PN1000~PN1800 |
| Extruder output | Max250kg/h |
| Line length | 63m×4.5m×4m(L×W×H) |
| Line center height | 1000mm |
| Total weight | 20T(approximately) |
| Installed power | 175kw |
