Optical Fiber Coloring/Rewinding Machine and Ink Jet Printer Equipment
1. Application of the machine
The equipment is mainly used to color the surface of optical fibers and makes it easy to identify the multifibers within the loose tube. Also used to rewind fibers. The machine is different to common coloring machine; it can be used to color three optical fibers at same time.
2. The description of all the units
2.1 Movable optical fiber pay-off unit
2.2 Take-up and pay-off tension control unit
2.3 Fiber coloring and material supply system
2.4 UV Curing Oven
2.5 Capstan and counter
2.6 Take-up and traversing unit
2.7 Release static system
2.8 Ink Jet System
2.9 Electric control system and software
3. The condition and protection for the equipment
Keep the equipment far away from the vibrating source and the disturbing source.
The nitrogen source and the compressed air source should be provided by the users. The purity of the Nitrogen is 99.999%. The supply capacity is 30L/min. The pressure of the compressed air is 0.5Mpa. The pressed air must be dry and without oil.
For more information, please contact us at any time.
