Design Capacity: | 30-50 Bottles Per Mins | Control: | Siemens PLC |
---|---|---|---|
Design Standard: | China Standard | After Service: | One Year Warranty |
Highlight: | disposable face mask making machine,automatic packing machine |
CMT hand sanitzer/Medical alcohol automatic filling machine
It is suitable for different factories to filled with all liquid types of hand sanitizer/medical alcohol, and can automatically cover and rotate the cover. This machine is suitable for filling round plastic or glass bottles. Special specifications can be customized.
The equipment characteristic:
1. 25 ~ 55 bottles per minute, the specific speed depends on the size and shape of the bottle.
2. Can be equipped with filling machine, vertical labeling machine, screen printing machine, etc.
3. English man-machine interface operation, easy to understand.
4. Linear design, can be easily connected with other machines.
5. Filling, uncovering, topping and capping are done by one machine.
6. All parts in contact with materials are made of high-quality stainless steel.
7. Imported programmable controller + imported touch screen control, stable performance and high reliability.
8. High labeling accuracy, good stability, smooth labeling, no wrinkles, no bubbles;
9. It can comprehensively realize the circumferential positioning and labeling of round bottles, small taper bottles, and square bottles.
1 | Total rate | 1.5KW |
2 | Power supply | 220V, 50Hz, 1P |
3 | Filling nozzle | 8 |
4 | Filling range | 50ml~500ml(Twice for filling 1000ml) |
5 | Filling error | ±1% |
6 | Working speed | 30~50pcs/min |
7 | Hopper Size | 80L (optional) |
8 | Air Consumption | 0.3~0.5MPa |
9 | Dimension | 2000mmx850x1650mm |
10 | Weight | 450kg |
