| Place of Origin: | China |
|---|---|
| Brand Name: | CMT |
| Certification: | CE, ISO |
| Model Number: | Customization |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Standard Export Package |
| Delivery Time: | 100 Working Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 Sets Year |
| Design Capacity: | 10000 - 50000 Ton/Year | Design Standard: | GB/T 18262-2000 |
|---|---|---|---|
| Control: | Siemens PLC | Turn-key Project: | Yes |
| Condition: | Brand New | Guarantee: | One Year |
| High Light: | woodworking press machine,wood working machinery |
||
Urea Formaldehyde UF PF Glue Adhesive Making Machine Wood-based Panel
|
ITEM
|
EQUIPMENT
|
SPEC.
|
QTY.
|
REMARK
|
| 1 | Reactor | 30m3 | 2 sets |
Which is patent product by SS304,Our patented products, with a mixer, thermometer, Sight glass, oil heater, the internal coil all polished to reduce the hanging glue, packing seal, outside installed half-pipe exchange, thickness of body:8mm,the effective volume of 30m3
|
| 2 |
Motor reducer
|
2 sets
|
Guotai Guomao brand helical gear reducer, with 30KW motor , china rack
|
|
| 3 |
Electronic scale for reactor
|
90T
|
2 sets
|
include display meter, terminal box, loading cell made by TOLEDO
|
| 4 | Bucket elevator | 1 set | Stainless steel shell, engineering plastic hopper, corrosion resistant belt, lifting amount of 50m3/h. | |
| 5 | Feeding urea of hopper | 12m³ | 1 set |
Stainless steel,the thickness Of body:4mm,with stainless steel mesh and pneumatic discharge plug valve
|
| 6 |
Feeding melamin of hopper
|
2m3
|
1 set
|
Stainless steel,the thickness Of body:3mm,cone bottom type
|
| 7 | Melamine electric weight | 3 T | 1 set | Including sensors, junction boxes, liquid crystal display instruments, Toledo brand,Supporting the Melamine tank use |
| 8 | Urea electric weight | 30T | 1 set | Including sensors, junction boxes, liquid crystal display instruments, Toledo brand,Supporting the urea hopper use |
| 9 |
Rotating chute
|
1 set
|
Supporting the urea hopper us
|
|
| 10 | Condenser | 60㎡ | 2 sets |
Parts Contacted with the media are stainless steel 304 material, row tube both ends with large flange removable, supporting 30 m3 reactor use.
|
