Payment & Shipping Terms:
|Capacity:||1275.072ton/Year||Volume Of Each Bottle:||30ml (Customization)|
|Production:||6700 Bottles / Hour||Suggestion Each Machine Line Area:||50m2|
|Suggestion Daily Working Time:||16 Hours|
humic acid fertilizer,
sulfuric acid plant
SPA Oil Production Line Project
We can design the production line according to your requirements. The following data is just for your reference.
Product volume: 30ml;
Production: 6700 bottles / hour (daily working time: 16 hours)
2. Schematic diagram of production line
3. Oil finished product
4. Machine List:
1. 2T water treatment equipment
2. 2T deployment of tanks
3. Bottle washing drying machine
3.1 According to shaped bottle samples provided by customers then designed the machine;
3.2 High pressure pump spray washing machine, high pressure wind knife drying system, mute high-pressure blower system, electric heating drying system;
3.3 Drying box double insulation device;
3.4 The water tank chassis frame made by 304 stainless steel;
3.5 Total power consumption: 25kw;
3.6 All control systems are using the domestic well-known brand accessories.
4. Liquid filling & Capping Machine
5. Labeling machine
6. Inkjet printer
6.1 Main technical parameters:
Jet printing functions and specifications:
Technical specifications: 5×7,7×9,16×16,16×24,24×24.
Jet printing NO.: one or two adjustable (mixed Chinese, English, digital).
The font height: 1.2mm-12mm.
Jet printing speed: 7m/s(5×7 lattice single line).
Continuous / delay printing, real-time printing.
Large capacity of international one or two font, total 7500 Chinese characters, and can store 50 common printed information.
The synchronous shaft encoder, M code wheel, fiber optic sensor, RS232 communication interface.
For more information, Please contact us as soon as possible.
|NO.||Machine name||Units of measurement||Qty|
|1||Water treatment equipment
|5||Bottle washing drying machine||Custom made||1|
|6||Liquid filling & Capping Machine||YGZ10/8||1|
|7||Round bottle labeling machine||Custom made||1|
For more information, pls contact me at any time.
Contact Person: Catherine
