| Place of Origin: | China |
|---|---|
| Brand Name: | CMT |
| Certification: | CE, ISO |
| Model Number: | Customization |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Standard Export Package |
| Delivery Time: | 3months |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50sets per year |
| Capacity: | 100-500tons/day | Turnkey Project: | Yes |
|---|---|---|---|
| Name: | Glass Production Line | ||
| High Light: | float glass production line,hot dip galvanizing line |
||
Main technical parameter:
1. Raw materials (The qualified powder material enters the factory)
The main raw materials are sand, dolomite, limestone, sodium carbonate, mirabilite, broken glass, etc. Sand has a sand storehouse, broken glass has a yard, the other raw materials are bag qualified powder that stored into the factory storage in the warehouse. After weighted by electronic scale, raw materials are mixed with mixer and through the belt into the kiln head stock bin.
2. Glass composition
|
Chemical composition |
SiO2 | Al2O3 | Fe2O3 | CaO | MgO | R2O | SO3 |
|
Percentage (%) |
72.40 | 0.90～1.0 | 0.10 | 8.3～9.4 | 4.00～4.50 | 14.00 | 0.20 |
| SN. | Project |
| 1 | Raw materials workshop |
| 2 | Production unites the workshop |
| 2.1 | Melt the section |
| 2.2 | Shaping section |
| 2.3 | Section that anneal |
| 2.4 | Cut and judge the section of the finished product |
| 2.5 | Bits of broken glass system |
| 3 | Affiliated facility |
| 3.1 | Compress the air and stand |
| 3.2 | Circulating water system |
| 3.3 | Laboratory |
| 4 | Support the distribution system |
| 5 | System ofNatural gas |
| 6 | Installation and cold adjustment (cold adjustment is about 120days) |
FOR MORE INFORMATION, DO NOT HESITATE TO CONTACT WITH US.
